Frameset
Frame
Alpha Gold Aluminium, internal cable routing, flat-mount disc, rack and mudguard mounts, 135x5 mm QR
Fork
SR Suntour NEX, coil spring, preload, 50 mm travel, 100x5 mm QR
Wheels
Hub front
Shimano 3.0 watt dynamo hub
Hub rear
Shimano QC300-HM, alloy, CentreLock, freewheel, 135x5 mm
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Tyre
Bontrager H2 Comp, reflective strip, wire bead, 30 tpi, 700x40 mm
Max tyre size
700x45 mm with or without mudguards
Drivetrain
Shifter
Shimano U4000, 9-speed
Rear derailleur
Shimano CUES U4000
Crank
ProWheel Pro alloy, 40T narrow-wide steel ring, 170 mm length
Bottom bracket
Sealed cartridge, 68 mm
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain
Shimano LG500
Pedal
Bontrager City pedals
Max. chainring size
1x: 42T, 2x: 36/22
Components
Saddle
Bontrager Boulevard
Seatpost
Alloy, adjustable suspension, 27.2 mm, 350 mm length
Handlebar
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips
Trek Ergonomic Comp, lock-on
Stem
Size: S, M
Bontrager alloy, 31.8 mm clamp, 85 mm length
Size: L, XL
Bontrager alloy, 31.8 mm clamp, Blendr compatible, 105 mm length
Brake
Shimano MT200 hydraulic disc
Brake rotor
Shimano RT10, CenterLock, 160 mm
Rotor size
Max brake rotor sizes: 160 mm front and rear
Accessories
*Light
Size: S, M, L, XL
Herrmans H-Trace ECO dynamo LED, taillight
Size: S, M, L, XL
Herrmans Nordic MR5, 100 Lumen, LED, headlight
Kickstand
Alloy, rear-mount kickstand
Cargo rack
Alloy rear rack, 25 kg max weight
*Mudguard
Size: S, M, L, XL
SKS plastic, front
Size: S, M, L, XL
SKS plastic, rear
Weight
Weight
M - 17.80 kg / 39.25 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
